Compact, Versatile Commodity Bins
The BROOKFIELD™ OmniBin Mini Range is the compact alternative to our larger OmniBin models. Designed for year‑round versatility, these bins handle grain, stock feed, pellets, fertiliser, seed, and more with the same quality and reliability BROOKFIELD is known for.
Ideal for farmers who need a smaller, multi-purpose solution, the Mini Range offers the flexibility to use it during sowing, feeding, and general grain handling operations.
Built for convenience and safety, the Mini Range is the safest, cleanest and simplest compact bin available.
Take a look at BROOKFIELD gear in action out in the field.
Capacity | OB60 | OB90 | OB120 | OB150 | |
|---|---|---|---|---|---|
Tonnes | (av. wheat/urea) | 4.5 | 7 | 9 | 11.5 |
Tonnes | (Av. fertiliser) | 6 | 9 | 12 | 15
|
Mounted on Chassis | OB60 | OB90 | OB120 | OB150 | |
|---|---|---|---|---|---|
Dimensions | Length | 5.7m | 6.9m | 8.2m | 9.5m
|
Width | 2.5m | 2.5m | 2.5m | 2.5m | |
Height | 3.1m | 3.1m | 3.1m | 3.1m |
Bin Only | OB60 | OB90 | OB120 | OB150 | |
|---|---|---|---|---|---|
Dimensions | Length | 3.2m | 4.4m | 5.7m | 6.9m |
Width | 2.3m | 2.3m | 2.3m | 2.3m | |
Height | 2.0m | 2.0m | 2.0m | 2.0m | |
Tray Length Required | 2.6m/8.5ft^ | 3.8m/12.5ft^ | 5.1m/16.7ft^ | 6.3m/20.7ft^ | |
Conveyor Overhang | 1.4m | 1.4m | 1.4m | 1.4m | |
Tare Weight (kg) | 950 | 1,400 | 1,850 | 300 |
…It just keeps getting better!!
Side Conveyor Model | OBSC60-MR |
|---|---|
Height *Based on a chassis height of 1.1m | 2.5m |
Reach | 3.5m |
For more specific information, contact the BROOKFIELD® sales team on 1800 774 274 or sales@brookfield.net.au
